Modern Portable Cabins is a reliable Prefabricated Structure Manufacturer in Nagpur, providing advanced and efficient building solutions for various industries. Prefabricated structures, also known as prefab buildings, are transforming the construction industry by offering faster, cost-effective, and highly durable construction alternatives.

These structures are manufactured in a controlled factory environment using modern machinery and high-quality materials. Once the components are completed, they are transported to the project site and assembled quickly, reducing construction time and on-site labor requirements.

At Modern Portable Cabins, we design and manufacture high-quality prefabricated buildings tailored to the specific needs of our clients. Our prefab structures are widely used for site offices, residential units, commercial spaces, warehouses, labor accommodations, classrooms, and temporary facilities.

  • Base frame used are of pressed mild steel channel section.
  • Main structural elements are of ā€˜C’ Channels 100 mm x 50 mm.
  • Cross members are of ā€˜C’ channel section size 75 mm x 40 mm.

  • Side & end frames made out of pressed sections of suitable profiles/pillars of sufficient strength.
  • 8 mm MDF board used for interior walls.
  • All steel sheets treated for corrosion resistance.
  • Vertically corrugated sheet panels continuously welded to top side and base structures.
  • All gaps sealed at edges and seams to prevent moisture ingress.

  • Interior panelling done with 8 mm MDF board.
  • Adequate insulation provided in roof structure.

  • Bottom frame provided with 18 mm thick plywood / bison panel / E-board.
  • Panels fixed using self-tapping screws.
  • PVC vinyl flooring fixed on panel surface.

  • Doors made from steel or aluminium frame.
  • Fitted with strong locking system.
  • Durable and weather-resistant design.

  • Aluminium sliding type powder coated windows.
  • Made from aluminium section with 4 mm thick tinted glass.

  • Concealed copper wiring suitable for 250V, 50Hz single phase AC supply.
  • 3/19 copper cable used for lighting circuits.
  • ISI marked copper wires in PVC conduits.
  • Small distribution board with MCB protection provided.

  • Epoxy Zinc Phosphate primer used.
  • Two final coats of synthetic epoxy paint applied.
  • Provides corrosion resistance and fire protection.
